Aluminum Alloy Woven Screen Wire Mesh Aluminum Mesh Insect Screening
| Attribute |
Value |
| Material |
Aluminum 3003 5052 5005 6061 |
| Feature |
Lightweight, corrosion resistance, conductivity properties |
| Uses |
Insect, window screen, air filtration, others |
| Application |
Architectural, industrial filtration, residential uses |
| Mesh count |
12*12 12*14 14*16 18*18 |
| Wire diameter |
0.3-1.2mm |
| Roll width |
0.5-1.5m |
| Roll length |
30m |
Aluminum Woven Wire Mesh Overview
Aluminum wire mesh is a type of woven wire mesh made from aluminum wires. It is similar to stainless steel wire mesh but is specifically crafted from aluminum material. It's often used in various applications due to its lightweight, corrosion resistance, and conductivity properties.
The aluminum screen mesh is created by weaving aluminum wire together, forming a square opening pattern. This mesh can be used for insect screening, window screen, air filtration, and other industrial and commercial purposes.
Applications of Aluminum Wire Mesh
As a leading aluminum wire mesh manufacturer & supplier, we specialize in manufacturing high-quality aluminum mesh screen products for a wide range of applications. Whether it's for architectural enhancements, industrial filtration, or residential uses, aluminum wire mesh combines reliability and performance to meet the diverse needs of our customers.
Aluminum wire mesh screen exhibits corrosion resistance similar to stainless steel in typical environments. However, they are susceptible to rapid corrosion when exposed to alkaline solutions, hydrochloric acid, and hydrofluoric acid. Despite these limitations, aluminum mesh screen finds extensive use across diverse industries such as aerospace, automotive, marine, and applications requiring conductivity.
Benefits of Aluminum Alloy Wires
The composition of aluminum wire mesh screen materials includes alloys like 5052, 1350, 5056, and 6061. Each alloy offers specific properties suitable for different applications.
- 5052 aluminum alloy: Provides excellent strength and corrosion resistance, making it ideal for marine and structural uses.
- 6061 aluminum alloy: Prized for its versatility, being employed in aerospace components and architectural elements.
